Product Features

1. Wide application range: it can have a cover box or a cover box (please indicate when purchasing the product), and can make single nails, double nails and reinforced nails (double nails at both ends and single nail in the middle /////), which is suitable for different customers' requirements and has regular nail spacing.

2. Small footprint, cost saving and labor reduction: The machine covers an area of 2800*2700*2000. It only takes two people to complete the nail box and packing process. The touch screen operation is simple and easy to learn, and the digital input is convenient and fast. According to different specifications and sizes of cartons, adjust the distance of the nails and the number of nails, and it can be completed within one minute.

3. The appearance of the machine is simple and generous, the quality of the whole machine is guaranteed, the head is made of special steel, the computer gong is precision machined, the electric tailgate is adjusted, the stepping motor is adopted, the size is accurate, the buffer is formed, and the scissors mouth is effectively controlled. The pressure is electrically adjusted with the thickness of the carton to prevent damage to the box.

4. Fast speed and high efficiency: dual servo drive, PLC control, accurate feeding, low mechanical failure rate. Taking 3-4 nails as an example (nail distance is less than 80mm), the hand speed can reach 60 sheets/minute. The paper feeding part of the front end of the main machine has a photoelectric induction function, so that the worktable rises with the decrease of cardboard, and automatically drops to the bottom when there is no cardboard, which is convenient for the next batch of loading. There is a counting device at the back of the host, which can freely set the number of stacks of finished boxes. When the cumulative quantity reaches the set value, the side-out conveyor starts to work and sends the carton to the paper receiving rack for convenient packaging.

Technical parameters
